รายละเอียดสินค้า
| Series | GOT SIMPLE SERIES |
|---|---|
| Type | GS21 MODEL |
| Power Supply (V) | 24 |
| Current Type | DC |
| Display | TFT |
| Display Colour | 65536 |
| Display Size (Inch) | 7 |
| Resolution (Pixels) | 640X480 |
| Internal Memory Capacity (MB) | 15 |
| Memory Card Slot | SD |
| USB | 1 |
| Ethernet Port | 1 |
| RS-232 | 1 |
| RS-422/485 | 1 |
| Network Options | MODBUS, ETHERNET, CC-LINK IEFB |
| Protection Class | IP65F |
POWER SUPPLY SPECIFICATION
| Item | Specifications | |
| GS2107-WTBD-N | ||
| Power supply voltage | 24VDC (+10%,-15%), ripple voltage 200 mV or less |
|
| Power consumption | Under the maximum load | 6.4 W (271 mA/24 V) or less |
| Backlight OFF | 3.8 W (158 mA/24 V) or less | |
| Inrush current | 17 A or less (6 ms, ambient temperature 25 ํC, at th maximum load) |
|
| Permissible instantaneous power failure time | Within 5 ms | |
| Noise immunity | conforms to IEC61000-4-4, 2 kV (power supply line) |
|
| Withstand voltage | 350VAC for 1 minute across power terminals and earth | |
| Insulation resistance | 500VDC across power terminals and earth, 10 MΩ or more by an insulation resistance tester |
|
