รายละเอียดสินค้า
| LCD Size | 7" | |
| LCD Type | TFT Color | |
| Colors | 16.7M colors | |
| Resolution | 800 x 480 | |
| Backlight | LED | |
| Luminance | 600 cd/m² | |
| Backlight Lifetime | 50,000 hours | |
| Touch Panel | 4 Wire Resistive | |
| Memory | 1 GB DDR3 | |
| Storage | 8 GB eMMC | |
| Operating System | Embedded Linux | |
| Programming Software | Canvas | |
|
Interface
|
SD Card | 1 SD Slot |
| COM1 | RS-422/485 | |
| COM2 | RS-232 | |
| Ethernet | 10/100/1000 BaseT 1 or 2 Port(s) | |
| USB Host | 1 Port | |
| Tool Port | 1 USB Device | |
| Audio | 1 Port or None | |
| Front Bezel | Plastic | |
| Input Power | DC 24 V (Class 2) | |
| Power Consumption | 7 W (MAX : 12 W) | |
| Item Weight | 0.612 kg (1.35 lbs) | |
| Dimension (mm) | 185 x 127 x 53 | |
| Panel Cut (mm) | 177 x 119 | |
|
Certifications
|
UL | UL61010-1 / UL61010-2-201 (E231117) |
| UL Hazardous | – | |
| CE |
Electromagnetic Compatibility Directive 2014/30/EU (EMC)
|
|
| FCC |
The 47 CFR, Part 2, Part 15, and Part 17 of FCC Requirement
|
|
| KC |
Registration of Broadcasting and Communication Equipments
|
|
|
Protection Class
|
IP68 (front), IP20 (rear) | |
| Type : 4X, 12 | ||
